Bosch 3 Ton 19 SEER2 / 9.5 HSPF2 R-454B Matched Ducted Heat Pump System
Model: BOVA-36RTB-M20S + BIVA-36RCB-M20XSKU: SYS-BS-PREM-3T
$6,140
In Stock
Shipping:Ships via freight truck (curbside delivery). A delivery appointment will be scheduled after your order is invoiced. Free shipping on orders over $2,000.
Installation:Professional installation available for $1,150 — add it below at checkout.
Checkout is invoice-based: no card is required online. We review your order and email a formal invoice with payment instructions.
Description
Factory-matched ducted heat-pump equipment for year-round whole-home heating and cooling. This bundle pairs the BOVA-36RTB-M20S outdoor heat pump with the BIVA-36RCB-M20X multi-position indoor air handler. The published matched-system rating is 19 SEER2 / 9.5 HSPF2, using R-454B refrigerant. Price covers the listed indoor and outdoor equipment only; auxiliary electric heat kit, thermostat, line set, pad, freight, electrical or duct changes, permits, and installation are separate. Have a licensed HVAC contractor confirm the AHRI match, refrigerant compatibility, electrical requirements, duct airflow, and Manual J load for the home before ordering.
Specifications
- System Type
- Matched ducted split heat pump
- Nominal Capacity
- 3 Ton (12,000 BTU/h per nominal ton)
- Outdoor Unit
- BOVA-36RTB-M20S
- Indoor Air Handler
- BIVA-36RCB-M20X
- Matched Efficiency
- 19 SEER2 / 9.5 HSPF2
- Refrigerant
- R-454B
- Power
- 208/230V, single phase
- Compressor
- Inverter-driven variable capacity
- AHRI Reference
- 214771711
- Bundle Includes
- Outdoor heat pump and matched indoor air handler
- Not Included
- Heat kit, thermostat, line set, pad, shipping, and installation
